Raing 額定:DC 30V 50mA

規格詳情說明：

ELECTRICAL (電(dian)氣特性):

(接(jie)觸(chu)電阻) INITIAL CONTACT RESISTANCE: 50mΩ Max.

(操作力(li)量) OPERATION FORCE: 400gf±100gf

(絕緣(yuan)電(dian)阻) INSULATION RESISTANCE: 100MΩ Min. 250VDC

(電氣(qi)壽命) ENDURANCE: 10,000 CYCLES

(耐電(dian)壓) WITHSTAND VOLTAGE: AC 500V  rms(50-60Hz)FOR  1  MIN  TRIP CURRENT:0.5mA

(使用溫度范圍) PRACTICAL TEMPERATURE RANCE: -16℃～+60℃

(耐焊性試驗) RESISTANCE TO SOLDERING HEAT TEST:

 *SOLDERING IRON METHOD:BIT TEMPERATURE 350±10℃ APPLICATION TIME OF SOLDERING IRON3±0.5SEC

  HOWEVER EXCESSIVE PRESSURE SHALL NOT BE APPLIED TO THE TERMINAL.

  *手焊接的時候溫度控制在 350±10℃,時間為 3±0.5 秒,但不能在排腳上施加異常壓力。

(耐冷試驗) COLD TEST:

  *THE SWITCH SHALL BE STORED AT A TEMPERATURE OF -25±3℃ FOR 96 HOURS.THEN THE SWITCH SHALL BE MAINTAINED

  AT STANDARD ATMOSPHERIC CONDITIONS FOR 1 HOUR AFTER WHICH MEASUREMENT SHALL BE MADE.

  *放置(zhi)在溫度(du)-25±3℃中 96 小時(shi)后(hou),再(zai)將放置(zhi)在常(chang)溫常(chang)濕(shi)的(de)環境中 1 小時(shi)后(hou)進行測試.

(耐熱(re)試驗) HEAT TEST:

  *THE SWITCH SHALL BE STORED AT ATEMPERATURE OF 70±2℃ FOR 96 HOURS.THEN THE SWITCH SHALL

   BE MAINTAINED ATSTANDARD ATMOSPHERIC CONDITIONS FOR 1 HOUR AFTER WHICH MEASUREMENT SHALL BE MADE.

  *放(fang)置(zhi)在(zai)溫(wen)度(du) 70±2℃中測(ce)(ce)試(shi)(shi) 96 小(xiao)時(shi)后(hou),再將放(fang)置(zhi)在(zai)常溫(wen)常濕的(de)環境中 1 小(xiao)時(shi)后(hou)進行測(ce)(ce)試(shi)(shi).
