Raing 額定: 3A/6A 125/250V

規格尺寸：10*15mm

安規：ENEC、CQC、CB等

1.ROCKER SWITCH MODEL SS01-1S

2.PCB CONNECTOR TYPE: SINGLE POLE SINGLE THROW

3.RATING: 3A/6A 125/250VAC

4.CONTACT RESISTANT: <20MΩ (INITIAL)

5.DIELECTRIC STRENGTH: 1500V 1MIN

6.INSULATION RESISTANCE: >100MΩ

7.MECHANICAL LIFE: >3000 CYCLES (500VDC BETWEEN OPEN CONTACTS)

8.ELECTRICAL LIFE: >10000 CYCLES

9.TEMPERATURE RISE AT THE TERMINAL: MAX.30'C

10. ALL MATERIALS ARE ROHS COMPLIANT

11.ACTUATOR & HOUSING COLOR: BLACK

12.ACTUATOR PRINTING

13.SOLDER ABILITY OF TERMINAL: MAX350'C,3S (NO PRESSURE MAY BE PLACED IN THE TERMINALS WHEN SOLDERING BY HAND)

MATERIAL (材質):

(轉子) ROLLER：BRASS,NICKEL PLATED

(基座) TERMINAL BASE: NYLON 66(94V-0)

(柄) ACTUATOR：PC(94V-0)

(彈簧) SPRING: STAINLESS

(接觸片) CONTACT：COPPER,SILVERPLATED

(端子) TERMINAL: BRASS,TIN PLATED

(接點) CONTACT：Ag CLAD COPPER Alloy

主要用途: 儀器設備、辦公設備、小家電、機頂盒、路由器、數字機盒、電氣設備、熱敏打印機等做電源控制
